Graph information
Shows the number of different IRQs received by the kernel. High disk or network traffic can cause a high number of interrupts (with good hardware and drivers this will be less so). Sudden high interrupt activity with no associated higher system activity is not normal.
| Field | Internal name | Type | Warning | Critical | Info |
|---|---|---|---|---|---|
| dma [16] | i16 | derive | Interrupt 16, for device(s): dma | ||
| Tick [3] | i3 | derive | Interrupt 3, for device(s): Tick | ||
| dwc_otg_hcd:usb1 [32] | i32 | derive | Interrupt 32, for device(s): dwc_otg_hcd:usb1 | ||
| 20200000.gpio:bank0 [49] | i49 | derive | Interrupt 49, for device(s): 20200000.gpio:bank0 | ||
| 20200000.gpio:bank1 [50] | i50 | derive | Interrupt 50, for device(s): 20200000.gpio:bank1 | ||
| 2000b880.mailbox [65] | i65 | derive | Interrupt 65, for device(s): 2000b880.mailbox | ||
| doorbell [66] | i66 | derive | Interrupt 66, for device(s): doorbell | ||
| Edge [75] | i75 | derive | Interrupt 75, for device(s): Edge | ||
| IRQ [77] | i77 | derive | Interrupt 77, for device(s): IRQ | ||
| mmc0 [82] | i82 | derive | Interrupt 82, for device(s): mmc0 | ||
| uart-pl011 [83] | i83 | derive | Interrupt 83, for device(s): uart-pl011 | ||
| No .label provided | iFIQ | derive | Interrupt FIQ () | ||
| This field has the following extra information: NOTE: The plugin did not provide any label for the data source iFIQ. It is in need of fixing. | |||||
Zooming is very easy, it's done in 3 clicks (regular clicks, no drag&drop):
- Click to define the start of zoom.
- Click to define the ending of zoom.
- Refresh.
You can use the interactive form too.
